5. Remove the torsion spring retainer
y
spring
from the top of the ring gear.
6. Remove the clutch housing / ring gear and roll cage
u
assembly
from the gearcase housing.
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
t
and torsion
7. Remove the RH output hub assembly
gearcase housing.
8. Remove pinion seal
pinion gear assembly
Inspect and clean the gearcase housing and replace
all oil seals and O-rings.
9. Inspect the pinion gear
missing teeth. Inspect the pinion bearing for signs of
wear and the pinion shaft seal surface for pitting.
FINAL DRIVE
i
from the
o
a
, internal retaining ring
, and
s
from the gearcase housing.
s
for chipped, broken or
8.59
8
