4. Install the four speaker cover fasteners
fasteners to specification.
TORQUE
Speaker Cover Fasteners:
7 in-lbs (.75 Nm)
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
BASE AUDIO DISPLAY PINOUT
q
. Torque
FACTORY-INSTALLED OPTIONS
PIN
FUNCTION
—
1
—
2
3
LEFT - FRONT
4
LEFT + FRONT
—
5
—
6
—
7
—
8
9
USB +5V
10
USB DATA -
11
USB DATA +
12
USB GROUND
—
13
—
14
—
15
—
16
—
17
18
RIGHT - FRONT
19
RIGHT + FRONT
20
GROUND, PMX
21
SW B+
—
22
—
23
13
13.31
