4.3 Accessories

Part Number Description
GC-POE- 20m Ethernet cable for
CABLE-20M GNSS Compass
GC-NMEA2000- 6m NMEA 2000 drop cable
CABLE for GNSS Compass
GC-SER- 20m serial breakout cable for
BREAK-20M GNSS Compass
GC-SER- 20m unterminated serial
CABLE-20M cable for GNSS Compass
POE- DC POE Injector
INJECTOR-DC
SUPPLY-24V 24 V DC Power Supply
CAR12VPWR Car auxiliary power outlet
supply
CABLE-FTDI USB to RS232 / RS422
cable 1 m
MOUNT-SUCT Suction Cup Antenna Mount
GC-CASE Rugged Transport Case
Table 7: Ordering Part Numbers for Accessories
v2.0
Notes
20m CAT5e Ethernet cable with RJ45
Compatible with Ethernet units only (GC2-POE)
IP67 environmentally sealed connector
See Ethernet Connection
6m NMEA 2000 drop cable
Compatible with serial units only (GC2-SER)
IP67 environmentally sealed connector
See NMEA 2000 Drop Cable
20m cable to DB9 connectors
Compatible with serial units only (GC2-SER)
IP67 environmentally sealed connector
See Serial Connection
20m unterminated cable
Compatible with serial units only (GC2-SER)
IP67 environmentally sealed connector
See Serial Connection
24V DC PoE Injector
25W 802.3at Type 2 "PoE+"
Requires 12/24V DC power supply (SUPPLY-24V,
CAR12VPWR or similar)
100-240 V AC Mains to 24 V DC Power Supply (DC jack)
Includes 2-pin plug types A/C/G/I
Car auxiliary power supply to 2.1 x 5.5mm DC jack
power supply
1 m FTDI USB to RS232 / RS422 (selectable) cable
Suction cup 5/8" GNSS antenna survey mount for easy
installation of GNSS antenna on vehicles.
Requires 5/8" to 1-14 UNS-2A thread adapter, not
supplied
Rugged Transport Case
Page 11
for full details
for full details
for full details
for full details
