6.5

Accessories

Part Number
GC-NMEA2000-CABLE-6M
GC-POE-CABLE-20M
GC-SER-BREAK-20M
GC-SER-CABLE-20M
POE-INJECTOR
CABLE-FTDI
SUPPLY-24V
CAR12VPWR
ILU
Table 7: Accessories part numbers
Description
6m NMEA 2000
drop cable for
GNSS Compass
20m Ethernet
cable for GNSS
Compass
20m serial
breakout cable for
GNSS Compass
20m serial cable
for GNSS
Compass
AC POE Injector
USB to RS232 /
RS422 cable 1 m
24V DC Power
Supply
Car cigarette
lighter power
supply
Interface and
Logging Unit
GNSS Compass Reference Manual
Page 16 of 85
Version 1.1
13/01/2021
6m NMEA 2000 drop cable
Compatible with serial units only (GC-SER-LC
and GC-SER-HA)
See section 7.8 for full details
IP68 environmentally sealed connector
20m CAT5e Ethernet cable with RJ45
Compatible with Ethernet units only (GC-POE-
LC and GC-POE-HA)
See section 7.9 for full details
IP68 environmentally sealed connector
20m cable to DB9 connectors
Compatible with serial units only (GC-SER-LC
and GC-SER-HA)
See section 7.10 for full details
IP68 environmentally sealed connector
20m unterminated cable
Compatible with serial units only (GC-SER-LC
and GC-SER-HA)
See section 7.11 for full details
IP68 environmentally sealed connector
100 to 240 V AC PoE Injector
FTDI USB to RS232 / RS422 (selectable) 1
metre cable
100-240V AC Mains to 24V DC Power Supply
(DC jack)
Includes 2-pin plug types A/C/G/I
Car cigarette lighter to 2.1 x 5.5mm DC jack
power supply
Interface and logging unit provides a
convenient option for logging and applications
that require multiple NMEA outputs
