GNSS Compass Reference Manual • Getting Started with GNSS Compass

3.1 NMEA 2000 Connection

Plug the NMEA 2000 drop cable into a T connector on the NMEA 2000 backbone. The unit will power on and
output the required NMEA 2000 messages without any configuration required. See
for more information.

3.2 NMEA 0183 Connection

Plug a 9 to 36 volt power source into the DC jack and connect the auxiliary RS422 port to the receiving
NMEA0183 device. See
recommended for NMEA 0183 installations. See

3.3 Power over Ethernet Connection

1. Plug the Ethernet cable from the GNSS Compass into the "Data+Power" port on the PoE injector. Plug an
Ethernet cable into the Data port and connect the other end to a DHCP router.
2. Install zeroconf (Apple Bonjour) from one of the links below:
https://www.advancednavigation.com.au/Bonjour.msi
https://www.advancednavigation.com.au/Bonjour64.msi
3. Open a web browser and type in the address
4. The default username is admin and the default password is password.
v2.0
Serial Connection for further details on the pin- out of the serial breakout cable
7.6 NMEA 0183 for further details on message configuration.
(32-bit installer)
(64-bit installer)
http://gnss-compass.local/
Page 6
NMEA 2000 Drop Cable
to access the web interface.
04 Nov 2021
