10.4.1.1 System Status
This field contains 16 bits that indicate problems with the system. These are boolean fields with a zero
indicating false and one indicating true.
Use the Raw GNSS packet #29 to identify which of the GNSS receivers or antennas has a problem.
Bit Description
0 System Failure
1 Accelerometer Sensor Failure
2 Gyroscope Sensor Failure
3 Magnetometer Sensor Failure
4 Reserved
5 GNSS Failure
6 Accelerometer Over Range
7 Gyroscope Over Range
8 Magnetometer Over Range
9 Reserved
10 Minimum Temperature Alarm
11 Maximum Temperature Alarm
12 Low Voltage Alarm
13 High Voltage Alarm
14 GNSS Antenna Connection (open or short circuit, primary or secondary
antenna)
15 Data Output Overflow Alarm
Table 45: System Status
