GNSS Compass Reference Manual • Advanced Navigation Packet Protocol
Port Ethernet Variant
Output rates Index
Table 112: Port Output Rates
10.5.9.3 Output Rates Index
Value Bit 3
0 0
1 0
2 0
3 0
4 0
5 0
6 0
7 0
8 1
9 1
Table 113: Output rates Index
10.5.10 User Data Packet
This packet is for storage of users data. The data itself is not used by GNSS Compass.
User Data Packet
Packet ID
Length
Read / Write
Field # Bytes Offset
1 0
Table 114: User Data Packet
v2.0
Bit 2 Bit 1
0 0
0 0
0 1
0 1
1 0
1 0
1 1
1 1
0 0
0 0
Data Type
Page 120
Serial Variant
Bit 0 Description
0 Disabled
1 0.1 Hz
0 0.2 Hz
1 0.5 Hz
0 1 Hz
1 2 Hz
0 5 Hz
1 10 Hz
0 25 Hz
1 50 Hz
198
64
Read / Write
Size Description
64 User Data
