GNSS Compass Reference Manual • Interfacing
9.1.2.3 NMEA Output
This function outputs a configurable combination of the NMEA messages GPZDA, GPGGA,
Descrip-
GPVTG, GPRMC, GPHDT, PASHR, GPROT, GPHEV, GPGSV, PFECGPAtt, and PFECGPHve
:
tion
at up to 50 Hz. The messages output and the output rate can be configured using the web UI or
GNSS Compass Manager. An example output is shown below.
$GPZDA,031644.460,07,05,2013,00,00*52
$GPGGA,031644.460,3352.3501851,S,15112.2355488,E,6,00,1.4,150
.0,M,0.0,M,,*7E
$GPVTG,089.19,T,089.19,M,000.00,N,000.00,K,E*27
$GPRMC,031644.460,A,3352.3501851,S,15112.2355488,E,0.0,89.2,0
70513,12.5,W,E*02
$GPHDT,89.2,T*06
$PASHR,031644.460,089.19,T,-00.01,-00.47,-00.00,,,,0,0*2E
9.1.2.4 ANPP Output
Description
:
9.1.2.5 TSS1 Output
:
Description
9.1.2.6 Simrad 1000 Output
Description
:
9.1.2.7 Simrad 3000 Output
Description
:
v2.0
This function outputs data in the ANPP format as specified in
Advanced Navigation Packet
peripheral devices only.
When this function is enabled, the auxiliary port functions the same
as the primary port, with two exceptions:
1. The auxiliary port cannot perform a firmware update.
2. When setting the ANPP packet and message output rates,
the changes only apply to the port you are connected to. For
example, you cannot change the primary port packet and
message rates when connected to the auxiliary port.
This function outputs the TSS1 format at a user configurable rate of
up to 50 Hz. The output rate can be configured using the page in the
web UI.
This function outputs the Simrad 1000 format at a user configurable
rate of up to 50 Hz. The output rate can be configured using the
8.1.3.3 Data Ports
Interface.
This function outputs the Simrad 3000 format at a user configurable
rate up to 50 Hz. The output rate can be configured using the
8.1.3.3 Data Ports
page in the
Protocol. This function is for ANPP
page in the
8.1 Using the Web User
8.1 Using the Web User
Page 68
10
Interface.
04 Nov 2021
