3 Getting Started

To get started with GNSS Compass for the first time, it is recommended that you begin by establishing
communications to the device, either before or after the unit is installed in its final location. These instructions
assume the use of components provided in the
supplied optional 4.3
1. Install the GNSS Compass in an area where it has a full clear view of the sky and away from strong radio
transmission sources as shown in
Figure 2: GNSS Compass ideal mounting location
2. Ensure that the GNSS Compass is aligned with the vessel such that the indicator on top is aligned pointing
forwards on the vessel. The sight can be used to assist alignment by eye. See
alignment.
v2.0
Accessories.
Figure 2: GNSS Compass ideal mounting location
3 Evaluation Kit , or purchased as Advanced Navigation
Page 4
Figure 3: GNSS Compass
