GNSS Compass Reference Manual • Getting Started with GNSS Compass
Part Number
Ethernet
GC2-EK-POE 1
GC2-EK-SER
CABLE-FTDI
SUPPLY-24V 1
GC-POE- 1
CABLE-20M
GC-SER-
BREAK-20M
POE- 1
INJECTOR-
v2.0
Quantity Description
Serial
GNSS Compass Ethernet
Variant
1 GNSS Compass Serial
Variant
1 RS232/422 Adaptor to
USB
1 24 V DC power supply
20m Ethernet cable for
GNSS Compass
1 20m serial breakout cable
for GNSS Compass
DC POE Injector
Page 8
Notes
GNSS Compass Ethernet variant
Power over Ethernet interface
Supports GPS, GLONASS,
Galileo & BeiDou constellation
L1/L2 10mm RTK
Supports DGPS and SBAS
Does not support L band
GNSS Compass Serial variant
RS422/RS232 and CAN interfaces
Supports GPS, GLONASS,
Galileo & BeiDou constellation
L1/L2 10mm RTK
Supports DGPS and SBAS
Does not support L band
FTDI USB to RS232 / RS422
(selectable) 1 metre cable
100-240 V AC Mains to 24 V DC
Power Supply (DC jack)
Includes 2-pin plug types A/C/G/I
20m CAT5e Ethernet cable with
RJ45
Compatible with Ethernet units
only (GC2-POE)
IP67 environmentally sealed
connector
See Ethernet Connection
details
20m cable to DB9 connectors
Compatible with serial units only
(GC2-SER)
IP67 environmentally sealed
connector
See Serial Connection
details
24V DC PoE Injector
25W 802.3at Type 2 "PoE+"
for full
for full
