GNSS Compass Reference Manual • Advanced Navigation Packet Protocol
10.4.24 Angular Acceleration Packet
Angular Acceleration Packet
Packet ID
Length
Read / Write
Field #
Bytes Offset
1
0
2
4
3
8
Table 72: Angular Acceleration Packet
10.4.25 External Position and Velocity Packet
External Position and Velocity Packet
Packet ID
Length
Read / Write
Field #
Bytes Off-
set
1
0
2
8
3
16
4
24
5
28
6
32
7
36
8
40
9
44
10
48
11
52
12
56
Table 73: External Position and Velocity Packet
v2.0
Data Type
Size
fp32
4
fp32
4
fp32
4
Data Type
Size
fp64
8
fp64
8
fp64
8
fp32
4
fp32
4
fp32
4
fp32
4
fp32
4
fp32
4
fp32
4
fp32
4
fp32
4
43
12
Read
Description
Angular acceleration X (rad/s/s)
Angular acceleration Y (rad/s/s)
Angular acceleration Z (rad/s/s)
44
60
Read / Write
Description
Latitude (rad)
Longitude (rad)
Height (m)
Velocity north (m/s)
Velocity east (m/s)
Velocity down (m/s)
Latitude standard deviation (m)
Longitude standard deviation (m)
Height standard deviation (m)
Velocity north standard deviation (m/s)
Velocity east standard deviation (m/s)
Velocity down standard deviation
(m/s)
Page 99
04 Nov 2021
