GNSS Compass Reference Manual • Installing GNSS Compass
Figure 11: Surface mounting shoulder washer
For instructions on alignment of the unit within a vehicle, see
6.3 Mounting
Alignment.
6.3 Mounting Alignment
The GNSS Compass should be aligned such that it is level with the vehicle and the indicator on the lid is directly
forward of the sight, see
Figure 12: GNSS Compass
alignment. The sight can be used to visually align the
indicator for best results. See
Figure 14: Alignment on a car
for example mounting on a boat and
Figure 14:
Alignment on a car
for example mounting on a car.
v2.0
Page 25
04 Nov 2021
