PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
4 RSLogix Example Program
In This Chapter

CompactLogix I/O Example .................................................................912

CompactLogix Messaging Example .......................................................92
There are three example ladder logic programs on the ProSoft Solutions DVD. Two projects
are for a CompactLogix system and one for a MicroLogix 1500 system. These examples can
be used as templates for starting your project. An explanation of each project is in the
following sections. If you are using another type of Controller, change the Controller Type in
RSLogix and then store it to your individual project. If you setup up a new controller project
you can use the Copy and Paste functionality of RSLogix to transfer the user defined data
types or ladder logic needed with the module PS69-DPM.
Sample Project
PS69_DPM_L32E.acd
PS69_DPM_Messaging_L32E.acd
ProSoft Technology, Inc.
October 1, 2014
Controller Type RSL5K Version
1769-L32E V13
1769-L32E V13
Description
Basic I/O example
Basic messaging example
