PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
CIP Message Parameters for MSAC1_Write
Parameter
Message Type
Service Type
Service Code
Class
Instance
Attribute
Source Element
Destination
Source Length
MSAL1M_Alarm_Res
The MSAL1M_Alarm_Res request is used by the master to send a DPV1 Alarm response to
a slave device. The message acknowledges the alarm when the appropriate indication
appears in theDPV1 Alarm Indication (page 67) area. The information mapped to this area
must be used in the DPV1 Alarm Response message in order to process the alarm properly.
The mapping of this information shall be as follows.
MSAL1M_ALARM_RES_REQUEST
Parameter
Reserved1
Reserved2
Reserved3
Command
Reserved4
DeviceAdr
SlotNum
SeqNum
AlarmType
AlarmSpec
Reserved5
ProSoft Technology, Inc.
October 1, 2014
Value
CIP Generic
Custom
64 hex
65 hex
1
0
WriteReq
WriteCnf
16 + x
( x = 1 .. 240 )
Data Type Value
INT 0
INT 0
INT 0
SINT 18
SINT 0
SINT 0.. 125
SINT 0.. 254
SINT 0.. 31
SINT 1 to 6,32 to
126
SINT 0..7
SINT 0
Remarks
Service Code "Bridge Message"
CIP Object "CIP_MSG_BRIDGE""
Reference to a Tag of type MSAC1_WRITE_REQUEST
Reference to a Tag of type
MSAC1_WRITE_CONFIRM
16 = Constant part of the service MSAC1_WRITE_REQUEST
x = Number of data to be transferred
Description
Reserved
Reserved
Reserved
Command for Service MSAL1M_Alarm_Res
Reserved
Address of the PROFIBUS Slave from DPV1 Alarm Indication
Register.
Slot Number from DPV1 Alarm Indication Register.
Sequence Number from DPV1 Alarm Indication Register.
Alarm Type from DPV1 Alarm Indication Register.
Alarm Spec from DPV1 Alarm Indication Register.
Reserved
