MSAL1M_Alarm_Res
Failure
86 hex = REJ_INT
87 hex = REJ_SRT
88 hex = REJ_ENA
89 hex = REJ_NPD
9a hex = REJ_COM
Page 90 of 130
Significance
The alarm handler is not
initialized
The alarm handler is currently
stopped
The alarm that shall be
acknowledged is not enabled in
slave parameter data
The alarm that shall be
acknowledge is not pending on
a MSAL1_Alarm_Res
Unknown msg.b command
PS69-DPM ♦ CompactLogix or MicroLogix Platform
Error source Help
DEVICE No DPV1 capable device configured within the
card
DEVICE No DPV1 capable slave device is in process
data exchange with the DEVICE. Check if
network is running
HOST Enable the corresponding alarm in slave
configuration data set
HOST Check the parameter Alarm_Type and
Seq_Nr. Both must be equal to the
MSAL1_Alarm_ind parameter
HOST Correct the requested msg.b parameter of
message
