PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
DDLM_SLAVE_DIAG_REQUEST
Parameter
Reserved1
Reserved2
Reserved3
Command
Reserved4
DeviceAdr
DataArea
DataAdr
DataIdx
DataCnt
DataType
Function
DDLM_SLAVE_DIAG_CONFIRM
Name
Reserved1
Reserved2
Answer
Failure
Reserved3
DeviceAdr
DataArea
DataAdr
DataIdx
DataCnt
DataType
Function
StationState_1
StationState_2
StationState_3
MasterAddress
IdentNumber
Reserved4
ExtDiag[0..99]
ProSoft Technology, Inc.
October 1, 2014
Data Type Value
INT 0
INT 0
INT 0
SINT 66
SINT 0
SINT 0..125
SINT
INT
SINT
SINT
SINT
SINT 1,3
Data Type Value
INT 0
INT 0
SINT 66
SINT e
INT 0
SINT 0 .. 125
SINT 0
INT 0
SINT 0
SINT 6 + x
SINT 0
SINT 1,3
SINT S1
SINT S2
SINT S3
SINT MA
INT ID
INT 0
SINT EX
Description
Reserved
Reserved
Reserved
Command for the DDLM_Slave_Diag service
Reserved
Address of the PROFIBUS Slave
Reserved
Reserved
Reserved
Reserved
Reserved
1 Read the diagnostic information from the internal buffer of
the Master
3 Read the diagnostic information directly from the Slave
Description
Reserved
Reserved
Answer DDLM_Slave_Diag
Error, Status (see following section)
Reserved
Slave Address
Reserved
Reserved
Reserved
Length of the diagnostic structure (starting with
StationState_1)
Reserved
Read function
Station status_1
Station status_2
Station status_3
Master address
Ident Number
Reserved
Extended Diagnostic
Contents
