ProSoft Technology PS69-DPM User Manual page 65

PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
Code Indication
56 Non Existing Slave Parameters
57 Faulty Parameter Value in a Slave
Parameters
58 Duplicate Slave Address
59 Projected Send Process Data Offset
Address of a Slave is Outside the
Limits of 0 to 255
60 Projected Receive Process Data
Offset Address of a Slave is Outside
the Limits of 0 to 255
61 Data-Areas of Slaves are
Overlapping in the Send Process
Data
62 Data-Areas of Slaves are
Overlapping in the Receive Process
Data
63 Unknown Process Data Handshake
64 Free RAM Exceeded
65 Faulty Slave Parameter Dataset
202 No Memory Segment Available
212 Faulty Reading of a Database
213 Structure Used by the Operating
System is Faulty
220 Software Watchdog Error
221 No Data Acknowledge in Process
Data Handshake
222 Master in Auto_Clear
225 No Further Segments
ERROR_EVENT Codes for an Err_Rem_ Adr of not equal to 255
Code Indication
2 Slave Station Reports Data
Overflow
3 Request Function of Master is not
Supported in the Slave
9 No Answer, Although the Slave
must Respond with Data
17 No Response from the Slave
ProSoft Technology, Inc.
October 1, 2014
Source Corrective Action
Configuration Execute download of configuration
database again.
Configuration Check GSD file for possible incorrect slave
parameterization values.
Configuration Check configured slave addresses in
project.
Configuration Check slave configuration in active project.
Configuration Check slave configuration in active project.
Configuration Check slave configuration in active project.
Configuration Check slave configuration in active project.
Master Problem with master's startup parameters.
Master Master has a hardware issue.
Configuration Check GSD file for possible incorrect slave
parameterization datasets.
Master Master has a hardware issue.
Configuration Execute download of configuration
database again.
Master Master has a hardware issue.
Host Firmware watchdog has an error.
Host Firmware is having trouble with Host
acknowledgement.
Slave Device The auto_clear mode was activated,
because one slave is missing during
runtime.
Master Contact hotline
Source Corrective Action
Master Telegram Check length of configured slave parameter
or configuration data.
Master Telegram Check if slave is PROFIBUS-DP norm
compatible.
Slave Check configuration data of the slave and
compare it with the physical I/O data
length.
Slave Check bus cable, and bus address of slave.
