  • Page 1 MVI71-GEC PLC 5 Platform Generic ASCII Ethernet Communication Module May 11, 2011 USER MANUAL...

  • Page 2: Your Feedback Please

    ® ProSoft Technology Product Documentation In an effort to conserve paper, ProSoft Technology no longer includes printed manuals with our product shipments. User Manuals, Datasheets, Sample Ladder Files, and Configuration Files are provided on the enclosed CD-ROM in ® Adobe Acrobat Reader file format (.PDFs).

  • Page 3: Important Installation Instructions

    Important Installation Instructions Power, Input, and Output (I/O) wiring must be in accordance with Class I, Division 2 wiring methods, Article 501-4 (b) of the National Electrical Code, NFPA 70 for installation in the U.S., or as specified in Section 18-1J2 of the Canadian Electrical Code for installations in Canada, and in accordance with the authority having jurisdiction.

  • Page 4: Markings

    Markings Electrical Ratings Backplane Current Load: 800 mA @ 5 Vdc Operating Temperature: 0° C to 60° C (32° F to 140° F) Storage Temperature: -40° C to 85° C (-40° F to 185° F) Shock: 30 g operational, 50 g non-operational; Vibration: 5 g from 10 Hz to 150 Hz Relative Humidity 5% to 95% (with no condensation) All phase conductor sizes must be at least 1.3 mm(squared) and all earth ground conductors must be at least 4mm(squared).

  • Page 5: Table Of Contents

    Important Installation Instructions ....................... 3 MVI (Multi Vendor Interface) Modules ....................3 Warnings ............................. 3 Battery Life Advisory ........................... 3 Markings .............................. 4 Guide to the MVI71-GEC User Manual Start Here System Requirements ..................... 10 Package Contents ....................11 Setting Jumpers ...................... 12 Install the Module in the Rack .................
  • Page 6 DB9 to RJ45 Adaptor (Cable 14) ................69 MVI71-GEC Status Data Area ................70 MVI71-GEC Configuration Data ................74 5.5.1 MVI71-GEC Server Communication Module Configuration ........74 Support, Service & Warranty Contacting Technical Support ......................77 Return Material Authorization (RMA) Policies and Conditions ....... 79 6.1.1...

  • Page 7: Guide To The Mvi71-Gec User Manual

    MVI71-GEC ♦ PLC 5 Platform Guide to the MVI71-GEC User Manual Generic ASCII Ethernet Communication Module User Manual Guide to the MVI71-GEC User Manual Function Section to Read Details Introduction Start Here (page 8) This section introduces the customer to the →...
  • Page 8 Guide to the MVI71-GEC User Manual MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Page 8 of 86 ProSoft Technology, Inc. May 11, 2011...

  • Page 9: Start Here

    Microsoft Windows: install and launch programs, execute menu commands, navigate dialog boxes, and enter data Hardware installation and wiring: install the module, and safely connect GEC and PLC devices to a power source and to the MVI71-GEC module’s application port(s) ProSoft Technology, Inc.

  • Page 10: System Requirements

    Rockwell Automation PLC processor, with compatible power supply and one free slot in the rack, for the MVI71-GEC module. The module requires 800mA of available power. The PLC Processor must provide for at least 64 words of BTR/BTW area, otherwise the module may not function correctly.

  • Page 11: Package Contents

    Generic ASCII Ethernet Communication Module User Manual Package Contents The following components are included with your MVI71-GEC module, and are all required for installation and configuration. Important: Before beginning the installation, please verify that all of the following items are present.

  • Page 12: Setting Jumpers

    Do not jumper the Setup pins together unless you are directed to do so by ProSoft Technical Support. The following illustration shows the MVI71-GEC jumper configuration. Note: If you are installing the module in a remote rack, you may prefer to leave the Setup pins jumpered.

  • Page 13: Install The Module In The Rack

    After you have checked the placement of the jumpers, insert MVI71-GEC into the PLC™ chassis. Use the same technique recommended by Rockwell Automation to remove and install PLC modules.
  • Page 14 Start Here MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module With a firm but steady push, snap the module into place. Check that the holding clips on the top and bottom of the module are securely in the locking holes of the rack.

  • Page 15: Connect Your Pc To The Processor

    MVI71-GEC ♦ PLC 5 Platform Start Here Generic ASCII Ethernet Communication Module User Manual Connect your PC to the Processor Connect the right-angle connector end of the cable to your controller at the communications port. Connect the straight connector end of the cable to the serial port on your computer.

  • Page 16: Download The Sample Program To The Processor

    Start Here MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Download the Sample Program to the Processor To download the sample program from RSLogix 5 to the PLC processor: Note: The key switch on the front of the PLC processor must be in the REM position.

  • Page 17: Configuring The Rslinx Driver For The Pc Com Port

    MVI71-GEC ♦ PLC 5 Platform Start Here Generic ASCII Ethernet Communication Module User Manual When the download is complete, RSLogix will open another confirmation dialog box. Click OK to switch the processor from Program mode to Run mode. Note: If you receive an error message during these steps, refer to your RSLogix documentation to interpret and correct the error.
  • Page 18 Start Here MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Click to select the driver, and then click C . This action opens the ONFIGURE Configure RS-232 DF1 Devices dialog box. Click the A button. RSLinx will attempt to configure your ONFIGURE serial port to work with the selected driver.

  • Page 19: Connect Your Pc To The Module

    MVI71-GEC ♦ PLC 5 Platform Start Here Generic ASCII Ethernet Communication Module User Manual Connect your PC to the Module With the module securely mounted, connect your PC to the Configuration/Debug port using an RJ45-DB-9 Serial Adapter Cable and a Null Modem Cable.
  • Page 20 Start Here MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Page 20 of 86 ProSoft Technology, Inc. May 11, 2011...

  • Page 21: Module Configuration

    IP Address ..................... 28 This section contains the setup procedure, data, and ladder logic for successful application of the MVI71-GEC module. Each step in the setup procedure is defined in order to simplify the use of the module. ProSoft Technology, Inc.

  • Page 22: Using Prosoft Configuration Builder

    The following illustration shows the ProSoft Configuration Builder window with a new project. Your first task is to add the MVI71-GEC module to the project. Use the mouse to select "Default Module" in the tree view, and then click the right mouse button to open a shortcut menu.
  • Page 23 Choose Module Type dialog box. In the Product Line Filter area of the dialog box, select MVI71. In the Select Module Type dropdown list, select MVI71-GEC, and then click OK to save your settings and return to the ProSoft Configuration Builder window.

  • Page 24: Renaming Pcb Objects

    Module Configuration MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module 2.1.2 Renaming PCB Objects Notice that the contents of the information pane and the configuration pane changed when you added the module to the project. At this time, you may wish to rename the Default Project and Default Location folders in the tree view.

  • Page 25: Module]

    This section of the file describes the database setup and module level parameters. [Module] Module Name: MVI71-GEC Communication Module DEFAULT Module Name 0 to 80 characters This parameter assigns a name to the module that can be viewed using the configuration/debug port.
  • Page 26 Module Configuration MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Enabled Yes or No This parameter determines if the server will be utilized by the module. If a value of "Yes" is entered, the server will be used. Any other value will disable the server.

  • Page 27: Downloading The Project To The Module Using A Serial Com Port

    MVI71-GEC ♦ PLC 5 Platform Module Configuration Generic ASCII Ethernet Communication Module User Manual 2.1.5 Downloading the Project to the Module Using a Serial COM Port For the module to use the settings you configured, you must download (copy) the updated Project file from your PC to the module.

  • Page 28: Ip Address

    User Manual Generic ASCII Ethernet Communication Module IP Address In addition to the GEC.CFG, the MVI71-GEC module requires a second configuration file that identifies its Ethernet configuration. Without this configuration file, the module will not communicate properly on the network.

  • Page 29: Ladder Logic

    Adding the Module to an Existing PLC5 Project ........30 GECServerStat (Server Status Object) ..........32 Ladder logic is required for the MVI71-GEC module to work. Tasks that must be handled by the ladder logic are module data transfer, special block handling, and status data receipt.

  • Page 30: Adding The Module To An Existing Plc5 Project

    Generic ASCII Ethernet Communication Module Adding the Module to an Existing PLC5 Project Add the MVI71-GEC module to the project. Right-click the mouse button on the I/O Configuration option in the Controller Organization window to display a pop-up menu. Select the New Module option from the I/O Configuration menu.
  • Page 31 MVI71-GEC ♦ PLC 5 Platform Ladder Logic Generic ASCII Ethernet Communication Module User Manual Select the 1769-Module (Generic 1769 Module) from the list and click OK. Enter the Name, Description and Slot options for your application, using the values in the illustration above. You must select the Comm Format as Data - INT in the dialog box, otherwise the module will not communicate over the backplane of the CompactLogix rack.

  • Page 32: Gecserverstat (Server Status Object)

    Ladder Logic MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module GECServerStat (Server Status Object) The GECServerStat object stores the status information related to each server on the module. All messages are counted for both receive and transmit operations.

  • Page 33: Diagnostics And Troubleshooting

    MVI71-GEC ♦ PLC 5 Platform Diagnostics and Troubleshooting Generic ASCII Ethernet Communication Module User Manual Diagnostics and Troubleshooting In This Chapter LED Status Indicators ................34 Using ProSoft Configuration Builder (PCB) for Diagnostics....36 Reading Status Data from the Module ..........43...

  • Page 34: Led Status Indicators

    Green Port not used Port not used Amber The MVI71-GEC is working normally. The MVI71-GEC module program has recognized a communication error. BP ACT Amber The LED is on when the module is performing a write operation on the backplane.

  • Page 35: Clearing A Fault Condition

    This indicates a problem with backplane communications. A problem flashes could exist between the processor and any installed I/O module, not just the MVI71-GEC. Verify that all modules in the rack are correctly configured in the ladder logic. Module Errors...

  • Page 36: Using Prosoft Configuration Builder (Pcb) For Diagnostics

    Diagnostics and Troubleshooting MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Using ProSoft Configuration Builder (PCB) for Diagnostics The Configuration and Debug menu for this module is arranged as a tree structure, with the Main menu at the top of the tree, and one or more sub-menus for each menu command.
  • Page 37 MVI71-GEC ♦ PLC 5 Platform Diagnostics and Troubleshooting Generic ASCII Ethernet Communication Module User Manual To connect to the module’s Configuration/Debug serial port Start PCB, and then select the module to test. Click the right mouse button to open a shortcut menu.

  • Page 38: Navigation

    On computers with more than one serial port, verify that your communication program is connected to the same port that is connected to the module. If you are still not able to establish a connection, contact ProSoft Technology for assistance.

  • Page 39: Main Menu

    Use these commands only if you fully understand their potential effects, or if you are specifically directed to do so by ProSoft Technology Technical Support Engineers. There may be some special command keys that are not listed on the menu but that may activate additional diagnostic or debugging features.
  • Page 40 Diagnostics and Troubleshooting MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Viewing Block Transfer Statistics Press [B] to view the Block Transfer Statistics screen. Use this command to display the configuration and statistics of the backplane data transfer operations between the module and the processor.
  • Page 41 MVI71-GEC ♦ PLC 5 Platform Diagnostics and Troubleshooting Generic ASCII Ethernet Communication Module User Manual Viewing Version Information Press [V] to view version information for the module. Use this command to view the current version of the software for the module, as well as other important values.

  • Page 42: Network Menu

    Diagnostics and Troubleshooting MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Viewing Server Configuration (Servers 0 to 4) Use commands [6] [7] [8] [9] or [0] to view the configuration of the specified server. Opening the Network Menu Press [@] to open the Network menu.

  • Page 43: Reading Status Data From The Module

    Press [M] to return to the Main menu. Reading Status Data from the Module The MVI71-GEC module returns a status data set to the PLC processor in each read block. This data is transferred to the PLC processor continuously with each read block.
  • Page 44 Diagnostics and Troubleshooting MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Page 44 of 86 ProSoft Technology, Inc. May 11, 2011...

  • Page 45: Reference

    Generic ASCII Ethernet Communication Module User Manual Reference In This Chapter Product Specifications ................46 Functional Overview ................48 Cable Connections ................66 MVI71-GEC Status Data Area ............... 70 MVI71-GEC Configuration Data ............74 ProSoft Technology, Inc. Page 45 of 86 May 11, 2011...

  • Page 46: Product Specifications

    Rockwell Automation processor and attached devices. The MVI71-GEC module is a powerful communication interface for PLC processors. Developed under license from Rockwell Automation, the module incorporates proprietary backplane technology that enables powerful data access between the module and the PLC processor.

  • Page 47: Functional Specifications

    MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual 5.1.3 Functional Specifications Five Servers and Clients to receive and/or transmit data 10/100 Base-T Ethernet-compatible interface Configurable parameters Service port number Connection timeout Close type Simple ladder logic operation Setup and monitoring through RS-Logix 5 software and user-constructed configuration file (GEC.CFG)

  • Page 48: Functional Overview

    Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Functional Overview 5.2.1 General Concepts The following discussion explains several concepts that are important for understanding module operation. Module Power Up On power up the module begins performing the following logical functions:...
  • Page 49 User Manual Block Transfer Backplane Data Transfer The MVI71-GEC module communicates directly over the PLC backplane. Data is paged between the module and the PLC processor across the backplane using BTR and BTW operations. Data is transferred from the module to the processor using the BTR blocks, and data is transferred from the processor to the module using BTW blocks.
  • Page 50 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Read Block These blocks of data transfer information from the module to the PLC processor. When data is received on one of the servers, a data block is built. The structure of this block type is shown in the following table.
  • Page 51 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Object in GSCInStat Block Description Offset Start Seq Number Sequence number for this block. Server Index For this status data block, this word is set to a value of -1.
  • Page 52 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Object in GSCInStat Block Description Offset Start Server[1].Port This word value contains the port address for the client connected to the server. Server[1].Open This status value contains the total number of times the server performed an open operation.
  • Page 53 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Object in GSCInStat Block Description Offset Start Server[2].CfgErrWord This bit mapped word defines the configuration errors for the server. Reserved 57 to 62 This data area is reserved for future use.
  • Page 54 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Object in GSCInStat Block Description Offset Start Server[3].Timeout This status value contains the total number of times a connection timeout occurred on the socket. Server[3].CfgErrWord This bit mapped word defines the configuration errors for the server.
  • Page 55 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Parameter Block Offset Description Start Operating system level as ASCII string Run number as ASCII string BlkErrs.Read Number of blocks transferred from module to processor BlkErrs.Write Number of blocks transferred from processor to module BlkErrs.Parse...
  • Page 56 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Parameter Block Offset Description Start Client[2].Connected This flag defines if the client is utilized and connected to a server. A value of 0 indicates the client is not connected and can be utilized for a connection.
  • Page 57 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Parameter Block Offset Description Start Client[3].IP 17 & 18 This double-word value contains the IP address of the server connected to the client. Client[3].Port This word value contains the port address for the server connected to the client.
  • Page 58 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Write Block These blocks of data transfer information from the PLC processor to the module. The structure of the BTW blocks used to transfer this data is shown in the following table.
  • Page 59 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual The last two words of the image control the server or the module. The server control word (word offset 62) controls the server. The following table lists the...
  • Page 60 User Manual Generic ASCII Ethernet Communication Module Handling Multiple Blocks An important concept to understand about the MVI71-GEC module is how multiple blocks are handled. The buffer size supports 4096 bytes, but the module can only send 110 bytes at each scan to the processor.
  • Page 61 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Side-Connect Backplane Data Transfer The side-connect interface is the simplest method to implement the module. Minimal ladder logic is required for the interface because the driver handles data movement between the module and the processor automatically.
  • Page 62 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module These files have fixed formats that are discussed below. Data received by the servers on the modules is passed to the read data file. The format of this file is shown in the following table.
  • Page 63 TCP/IP connection must be made between a client and a server on the module. The MVI71-GEC module contains five servers that listen on the user assigned service ports waiting for a connection. When a client devices wishes to send data to the module, it must open a TCP/IP connection to the module.
  • Page 64 User Manual Generic ASCII Ethernet Communication Module The MVI71-GEC module servers are configured to handle their TCP/IP session independently. The user parameter Connection Timeout is utilized to determine the amount of time a connection can remain idle before the server will close the connection.
  • Page 65 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Each server has a state value in the status data area. This value is utilized by the ladder logic to determine if a connection is present on server. The following table...

  • Page 66: Cable Connections

    One RS-232 Configuration/Debug port (RJ45 connector) 5.3.1 Ethernet Connection The MVI71-GEC module has an RJ45 port located on the front of the module, labeled Ethernet, for use with the TCP/IP network. The module is connected to the Ethernet network using an Ethernet cable between the module’s Ethernet port and an Ethernet switch or hub.

  • Page 67: Rs-232 Configuration/Debug Port

    MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual 5.3.2 RS-232 Configuration/Debug Port This port is physically an RJ45 connection. An RJ45 to DB-9 adapter cable is included with the module. This port permits a PC-based terminal emulation program to view configuration and status data in the module and to control the module.
  • Page 68 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Notice how the DF1 driver is opened, and the driver is looking for a processor on node 1. If the network is being browsed, then you will not be able to stop this driver.

  • Page 69: Db9 To Rj45 Adaptor (Cable 14)

    MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual You may now use the com port to connect to the debug port of the module. Note: You may need to shut down and restart your PC before it will allow you to stop the driver (usually only on Windows NT machines).

  • Page 70: Mvi71-Gec Status Data Area

    Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module MVI71-GEC Status Data Area This section contains a listing of the data contained in the MVI71-GEC status data object. Object In GSCInStat Block Offset Description Start PassCnt...
  • Page 71 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Object In GSCInStat Block Offset Description Start Server[1].IP This double-word value contains the IP address of the client connected to the server. Server[1].Port This word value contains the port address for the client connected to the server.
  • Page 72 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Object In GSCInStat Block Offset Description Start Server[2].Timeout This status value contains the total number of times a connection timeout occurred on the socket. Server[2].CfgErrWord This bit mapped word defines the configuration errors for the server.
  • Page 73 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual Object In GSCInStat Block Offset Description Start Server[4].RxCount This status value contains the total number of messages received by the server. Server[4].RxOverflow This status value contains the total number of messages received that exceed the specified buffer size for the server.

  • Page 74: Mvi71-Gec Configuration Data

    MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module MVI71-GEC Configuration Data This section contains a listing of the parameters and their definitions for the MVI71-GEC module configuration file definition. 5.5.1 MVI71-GEC Server Communication Module Configuration [Section]/Item Value Range Description [MODULE]...
  • Page 75 MVI71-GEC ♦ PLC 5 Platform Reference Generic ASCII Ethernet Communication Module User Manual [Section]/Item Value Range Description [Server n] Server definitions Enabled: Yes or This parameter determines if the server will be utilized by the module. If a value of "Yes' is entered, the server will be used.
  • Page 76 Reference MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Page 76 of 86 ProSoft Technology, Inc. May 11, 2011...

  • Page 77: Support, Service & Warranty

    Return Material Authorization (RMA) Policies and Conditions ....79 LIMITED WARRANTY ................81 Contacting Technical Support ProSoft Technology, Inc. (ProSoft) is committed to providing the most efficient and effective support possible. Before calling, please gather the following information to assist in expediting this process:...
  • Page 78 Support, Service & Warranty MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Web Site: www.prosoft-technology.com/support Internet E-mail address: support@prosoft-technology.com Tel: +603.7724.2080, E-mail: asiapc@prosoft-technology.com Asia Pacific (location in Malaysia) Languages spoken include: Chinese, English Tel: +86.21.5187.7337 x888, E-mail: asiapc@prosoft-technology.com...

  • Page 79: Return Material Authorization (Rma) Policies And Conditions

    The following Return Material Authorization (RMA) Policies and Conditions (collectively, "RMA Policies") apply to any returned product. These RMA Policies are subject to change by ProSoft Technology, Inc., without notice. For warranty information, see Limited Warranty (page 81). In the event of any inconsistency between the RMA Policies and the Warranty, the Warranty shall govern.

  • Page 80: Returning Units Under Warranty

    Return Material Authorization i. If a defect is found and is determined to be customer generated, or if the defect is otherwise not covered by ProSoft Technology s warranty, there will be no credit given. Customer will be contacted and can request module be returned at their expense;...

  • Page 81: Limited Warranty

    This Limited Warranty ("Warranty") governs all sales of hardware, software, and other products (collectively, "Product") manufactured and/or offered for sale by ProSoft Technology, Incorporated (ProSoft), and all related services provided by ProSoft, including maintenance, repair, warranty exchange, and service programs (collectively, "Services"). By purchasing or using the Product or Services, the individual or entity purchasing or using the Product or Services ("Customer") agrees to all of the terms and provisions (collectively, the "Terms")

  • Page 82: What Is Not Covered By This Warranty

    Support, Service & Warranty MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module 6.2.2 What Is Not Covered By This Warranty a) ProSoft makes no representation or warranty, expressed or implied, that the operation of software purchased from ProSoft will be uninterrupted or error free or that the functions contained in the software will meet or satisfy the purchaser’s intended use or requirements;...

  • Page 83: Intellectual Property Indemnity

    MVI71-GEC ♦ PLC 5 Platform Support, Service & Warranty Generic ASCII Ethernet Communication Module User Manual 6.2.4 Intellectual Property Indemnity Buyer shall indemnify and hold harmless ProSoft and its employees from and against all liabilities, losses, claims, costs and expenses (including attorney’s fees and expenses) related to any claim, investigation, litigation or proceeding (whether or not ProSoft is a party) which arises or is alleged to arise from Buyer’s...

  • Page 84: Limitation Of Remedies

    Support, Service & Warranty MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module 6.2.6 Limitation of Remedies ** In no event will ProSoft or its Dealer be liable for any special, incidental or consequential damages based on breach of warranty, breach of contract, negligence, strict tort or any other legal theory.

  • Page 85: Index

    User Manual GECServerStat (Server Status Object) • 32 General Concepts • 48 Index General Specifications • 46 Guide to the MVI71-GEC User Manual • 7 Handling Multiple Blocks • 60 [Module] • 25 Hardware Specifications • 46 [Server x] • 25 How to Contact Us •...

  • Page 86: Prosoft Technology, Inc

    Support, Service & Warranty MVI71-GEC ♦ PLC 5 Platform User Manual Generic ASCII Ethernet Communication Module Warnings • 3 What Is Covered By This Warranty • 81, 83 Read Block • 50 What Is Not Covered By This Warranty • 82 Reading Status Data from the Module •...
