PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
Failure Significance
17 = No response of the station
CON_NA
18 = Master not into the logical token ring Network in general
CON_DS
54 = Negative response received, access
CON_AD denied
MSAC1_Read and MSAC1_Write
Failure Significance
0 = CON_OK Service was executed without an
error
2 = CON_RR Resource unavailable
3 = CON_RS Requested function of master is not
activated within the slave
9 = CON_NR No answer-data, although the slave
has to response with data
17 = CON_NA No response of the station
18 = CON_DS Master not into the logical token ring Network in
25 = CON_NP No plausible reaction of remote
partner
54 = CON_AD Negative response received, access
denied
81 hex = DEVICE is about to stop the DPV1-
REJ_SE communication or the DPV1 is not in
OPEN state
82 hex = DEVICE has stopped the DPV1
REJ_ABORT communication automatically
83 hex = A previous service is still in process
REJ_PS
84 hex = The length indicator msg.data_cnt
REJ_LE exceeds maximum configured size
85 hex = REJ_IV Wrong parameter in request
9a hex = Unknown msg.b command
REJ_COM
ProSoft Technology, Inc.
October 1, 2014
Error source Help
Slave Check network wiring, check bus address of
Slave or baud rate support
Check master DP address or highest-station-
address of other Masters. Examine bus wiring
for bus short circuits.
Slave access denied
Error source Help
Slave Slave has no buffer space left for the
requested service
Slave Slave is not activated in its DPV1support
Slave Slave has not sent any data back
Slave Check network wiring, check bus address of
Slave or baud rate support
Check Master DP address or highest-station-
general address of other Masters. Examine bus wiring
to bus short circuits
Slave Slave does not conform to DPV1 norm
Slave Access denied to requested data. Check
Error_Code_1 and Error_Code_2 in response
message to get further error information
HOST, DPV1 communications must be configured to
configuration be activated by the DEVICE
Slave A previously addressed Slave has responded
with non conform parameters
HOST Wait for the outstanding answer first. Parallel
services are not allowed
HOST Reduce length of message or enlarge
maximum buffer size in PROSOFT.fdt
(SYCON.net) or in SLAVE data set
HOST Check msg.function or msg.device_adr
parameter of requested message
HOST Correct the requested msg.b parameter of
message
