1.5 Programmable Controller Functionality
PROFIBUS-DP supports acyclic services through messages. These PROFIBUS-DP
services are supported by the RSLogix 5000 programming tool using CIP messages. Not all
of the Programmable Controllers support CIP messaging. If the Controller does not support
messaging, the named acyclic PROFIBUS-DP services are not available.
The basic PROFIBUS-DP acyclic services Global Control or Slave Diagnostic request are
also executable in addition to the CIP method by using the I/O area. Follows is a matrix of
Programmable Controllers and the functionality that they support.
CompactLogix System
Processor/ Features
I/O
CIP Messaging
MicroLogix 1500 System
Processor/ Features
I/O
CIP Messaging
yes = functionality supported
no = functionality not supported
1.6 Package Contents
The following components are included with your PS69-DPM module, and are all required
for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are present.
Qty. Part Name
1 PS69-DPM Module
1 Cable
1 ProSoft Solutions
DVD
If any of these components are missing, please contact ProSoft Technology Support for
replacement parts.
Page 10 of 130
1769-L20 1769-L30
yes yes
no no
1764-LRP 1764-LSP
yes yes
no no
Part Number
PS69-DPM
CABLE-SRV-MD8
DVD-001
PS69-DPM ♦ CompactLogix or MicroLogix Platform
1769-L31 1769-L32E
yes yes
yes yes
Part Description
PROFIBUS DPV1 Master
For Connection to Module's Port
Contains sample programs, utilities and
documentation for the PS69-DPM module.
PROFIBUS DPV1 Master
1769-L35E
yes
Yes
