User Manual
1.8.4 Adding Multiple Modules (Optional)
Important: If your application requires more than one PS69-DPM module into the same project, follow the steps
below and make certain that both modules are assigned identical Block Transfer Sizes.
In the I/O Configuration folder, click the right mouse button to open a shortcut menu, and then choose New
Module.
1
Select 1769-MODULE.
Page 22 of 130
PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
ProSoft Technology, Inc.
October 1, 2014
