GLOBAL-BITS
Bit Offset Member Name
0 Ctrl
1 Aclr
2 Nexc
3 Fat
4 Eve
5 NRdy
6 Tout
7 Reserved1
ERROR-EVENT Codes for an Err_Rem_adr of 255
Code Indication
0 No errors
50 USR_INTF-Task Not Found
51 No Global Data
52 FDL-Task Not Found
53 PLC-Task Not Found
54 Non Existing Master Parameters
55 Faulty Parameter Value in the
Master Parameters
Page 64 of 130
PS69-DPM ♦ CompactLogix or MicroLogix Platform
Data Type Signification
BOOL CONTROL-ERROR Parameterization error
BOOL AUTO-CLEAR-
ERROR
BOOL NON-EXCHANGE-
ERROR
BOOL FATAL-ERROR
BOOL EVENT-ERROR
BOOL HOST-NOT-
READY-
NOTIFICATION
BOOL TIMEOUT-ERROR
BOOL Reserved
Source
None
Master
Master
Master
Master
Master
Configuration
PROFIBUS DPV1 Master
Meaning if Bit is set
Module stopped communication
with all slaves and reached the
auto-clear-end state.
At least one slave has not reached
the data exchange state and no
process data will be exchanged.
Because of major bus error, no
further bus communication is
possible.
The module has detected bus short
circuits. The number of detected
events is contained in the
Bus_error_cnt variable. This bit is
set when the first event was
detected and will remain set.
Indicates if the Application program
has set its state to operative or not.
If this bit is set the Application
program is not ready to
communicate
The module has detected an
overstepped timeout supervision
value because of rejected
PROFIBUS telegrams. It is an
indication for bus short circuits
while the master interrupts the
communication. The number of
detected timeouts is available in
the Time_out_cnt variable. This bit
will be set when the first timeout is
detected and will remain set.
Reserved
Corrective Action
None.
Firmware is invalid. Module must be
updated.
Firmware is invalid. Module must be
updated.
Firmware is invalid. Module must be
updated.
Firmware is invalid. Module must be
updated.
Execute download of configuration
database again.
Firmware is invalid. Module must be
updated.
