MSAL1M_ALARM_RES_CONFIRM
Parameter
Reserved1
Reserved2
Answer
Failure
Reserved3
DeviceAdr
SlotNum
SeqNum
AlarmType
AlarmSpec
Reserved5
CIP Message for MSAL1M_Alarm_Res
Parameter
Message Type
Service Type
Service Code
Class
Instance
Attribute
Source Element
Destination
Source Length
Page 86 of 130
Data Type Value
INT 0
INT 0
SINT 18
SINT E
INT 0
SINT 0.. 125
SINT 0.. 254
SINT 0.. 31
SINT 1 to 6,32 to
126
SINT 0..7
SINT 0
Value Remarks
CIP Generic
Custom
64 hex Service Code "Bridge Message"
65 hex CIP Object "CIP_MSG_BRIDGE""
1
0
AlarmReq Reference to a Tag of type MSAL1M_ALARM_RES_REQUEST
AlarmCnf Reference to a Tag of type
MSAL1M_ALARM _RES_CONFIRM
14 14 is constant for the Source Length of the MSAL1M_Alarm_Res
PS69-DPM ♦ CompactLogix or MicroLogix Platform
Meaning
Reserved
Reserved
Answer MSAL1M_Alarm_Res
Error, status (see following section)
Reserved
Address of the PROFIBUS Slave from DPV1 Alarm Indication
Register.
Slot Number from DPV1 Alarm Indication Register.
Sequence Number from DPV1 Alarm Indication Register.
Alarm Type from DPV1 Alarm Indication Register.
Alarm Spec from DPV1 Alarm Indication Register.
Reserved
