PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
MSAC1_READ_CONFIRM
Name Data Type
Reserved1 INT
Reserved2 INT
Answer SINT
Failure SINT
Reserved3 INT
DeciceAdr SINT
DataArea SINT
DataAdr INT
DataIdx SINT
DataCnt SINT
DataType SINT
Function SINT
if ‚Failure' = CON_AD
Data[0] SINT
Data[1] SINT
if ‚Failure' = 0
Data[0..x-1] SINT
CIP Message Parameters for MSAC1_Read
Parameter
Message Type
Service Type
Service Code
Class
Instance
Attribute
Source Element
Destination
Source Length
ProSoft Technology, Inc.
October 1, 2014
Value
0
0
17
E
0
0.. 125
0
0.. 254
0.. 254
X
= 1.. 240
0
1
Value Remarks
CIP Generic
Custom
64 hex Service Code "Bridge Message"
65 hex CIP Object "CIP_MSG_BRIDGE"
1
0
ReadReq Reference to a Tag of type
MSAC1_READ_REQUEST
ReadCnf Reference to a Tag of type
MSAC1_READ_CONFIRM
16 Corresponds to the size of the MSAC1_READ_REQUEST structure
Description
Reserved
Reserved
Answer MSAC1_Read
Error, status (see following Section)
Reserved
Address of the Slave
Reserved
Slot Number
Index
Length of the received data block
Reserved
MSAC1_Read
Error_Code_1
Error_Code_2
Data to be received from the Slave
Contents
