PS69-DPM ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
6.3.4 Input: DPM_GLOBAL_STATE_FIELD
Name
Ctrl
Aclr
Nexc
Fat
Eve
NRdy
Tout
Reserved1
DPM_State
Err_rem_adr
Err_event
Bus_err_cnt
Time_out_cnt
Reserved
Sl_cfg
Sl_state
Sl_diag
6.3.5 Input: DPM_SLAVE_DIAG_DATA
Name
SlaveAddress
Sta1_StationNotExist
Sta1_StationNotReady
Sta1_CfgFault
Sta1_ExtDiag
Sta1_NotSupp
Sta1_InvalidResponse
Sta1_PrmFault
Sta1_MasterLock
Sta2_PrmReq
Sta2_StatDiag
Sta2_Slave
Sta2_Watchdog
Sta2_FreezeMode
Sta2_SyncMode
Sta2_Reserved
Sta2_Deactivated
Sta3_Reserved0
Sta3_Reserved1
ProSoft Technology, Inc.
October 1, 2014
Data Type
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
SINT
SINT
SINT
INT
INT
SINT[8]
BOOL[128]
BOOL[128]
BOOL[128]
Data Type
SINT
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
Description
Control error
Auto clear error
Non exchange error
Fatal error
Event error
Host not ready notification
Timeout
Reserved
Master main state
Faulty remote address
Error Number
Heavy bus error counter
Number of rejected PROFIBUS Telegr.
Reserved
Slave Config
Slave State
Slave Diag
Description
Slave address
No response
Station not ready
Configuration faulty
Extended diagnostic
Sync,Freeze not supported
Response faulty
Parameters faulty
Locked by a master
Request new parameter
Static diagnostic
Set to 1 by a slave
Watchdog ON/OFF
Freeze mode active
Sync mode active
Reserved
Slave deactivated
Reserved
Reserved
