3 Set the Module Properties values as follows:
Parameter
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance
Configuration Size
4 On the Connection tab, check or un-check, as desired the M
Page 16 of 130
PS69-DPM ♦ CompactLogix or MicroLogix Platform
Value
Enter a module identification string. Example: PS69PDPMV1
Enter a description for the module. Example: PROFIBUS
DPV1 Master.
Select D -INT
ATA
Enter the slot number in the rack where the PS69-DPM
module will be installed.
101
248
100
248
102
0
PROFIBUS DPV1 Master
F option.
AJOR AULT
