Avaya CS 1000 Fundamentals page 118

System configuration
The SIP Line Gateways in Main Office and Branch Office must have the same configuration
values for domain name for SIP Line and the user name and password for each SIP DECT
user.
The primary proxy in Communication Server 1000 Survivable Branch Office is configured to
the Main Office SLG IP address to reduce registration time in normal operation mode when
the Main Office is operating correctly. The primary proxy is the first proxy in the list in the
configuration file and in the Gatekeeper Overview window.
Use Configuring multiple SIP proxies
IP DECT Configurator (IP settings). In the example in the following procedure, the Branch
Office SIP Line Gateway IP address 192.168.32.135 is added as an Alternate Proxy for SIP
DECT.
Configuring multiple SIP proxies
1. On the Settings pane, click IP DECT Configurator IP Settings
2. Select the Proxy IP Configuration tab and check the Multiple gatekeepers option.
3. In the Proxy IP address field, enter a value for proxy IP address.
4. In the Proxy port field, enter a value for proxy port.
5. Click OK.
118 SIP DECT Fundamentals
The IP Settings page appears, as shown in
Settings window on page 118.
Figure 36: IP DECT Configurator IP Settings window
Open the context menu on the table and select New.
Note:
The proxy port value must correspond to the proxy port value configured in SIP
Line.
Comments? infodev@avaya.com
on page 118 to configure multiple SIP proxies using the
Figure 36: IP DECT Configurator IP
October 2012
