Brainlab CURVE DUAL System User's Manual page 96

Sterile Use
How to Use the
Touchscreen
Sterilely
Step
To press a button or activate a function, use the Sterile Touchpen tip to touch the correspond-
ing area on touchscreen surface.
Sterile Field
Disposal
96
Maintaining the sterile field can only be guaranteed by using a Sterile Touchpen to
control the software on the Curve system. Do not drape the monitors, as draping may
cause overheating or other malfunction.
Do not touch the Sterile Touchpen tip after contacting the touchscreen with it. Do not
return the Sterile Touchpen to the sterile table after it has come in contact with the
touchscreen.
Avoid patient contact with the Sterile Touchpen. Do not allow fluids to come in contact
with the Sterile Touchpen. If the Sterile Touchpen comes in contact with the patient or
fluids, dispose of it immediately.
To maintain sterility, dispose of the Sterile Touchpen after each touchscreen interac-
tion.
System User Guide Rev. 1.0 Curve Dual Display, Curve Single Display Ver. 1.0
Figure 43
