CAMERA CART
4.3

Cabling

4.3.1

Cable Attachment

General Both the Curve Single Display and Curve Dual Display systems offer wired camera communica-
Information tion with the Monitor Cart. The cabling procedure for wired camera communication is described be-
low.
Follow the cabling procedure on page 70, for the use of wireless camera communication with the
Curve Dual Display system.
Cabling
Precautions
How to Attach
Cables for Wired
Steps
Camera
Communication
System User Guide Rev. 1.0 Curve Dual Display, Curve Single Display Ver. 1.0
Risk of electrical shock: Do not touch cable plugs when Monitor Cart is turned on.
Do not connect or disconnect cables when system is turned on.
Ensure that camera cable is not attached to any other device than the Monitor Cart.
Do not tug on or pull cables with any force.
1. Ensure that Monitor Cart is turned off.
2. Connect camera cable to camera port on the Monitor Cart.
3. Connect camera cable to camera port on the Camera Cart.
4. Lightly pull the cable at each end to check that locking mechanism is engaged.
5. Connect mains power to Monitor Cart and wall power outlet.
6. Power up system by switching on the Monitor Cart.
67
