Brainlab CURVE DUAL System User's Manual page 70

Cabling
How to Attach For wireless camera communication with the Curve Dual Display system, follow the below cabling
Cables for Wireless procedure:
Camera
Communication
Steps
Transition from You can transition from wireless to wired communication at any time by attaching the camera cable
Wireless to Wired (see page 67).
Communication
It is not recommended to change from wired to wireless communication while the system is running,
as it may cause the system to freeze, requiring a restart.
To change from wired to wireless communication:
Steps
System Pairing Wireless communication is fixed to a specific pairing of devices. Ensure that the correct paired sys-
tem is present in the OR, otherwise wireless communication is not possible.
Your system is delivered with the Camera Cart and Monitor Cart already paired. Should you need
to re-pair the system, connect the Camera Cart and Monitor Cart with the provided camera cable
and power on the system. The carts will automatically be paired once connected.
70
1. Ensure that Monitor Cart is turned off.
2. Plug in Camera Cart mains power (see page 70).
Allow camera to fully power up, i.e., LEDs are on and beeping is audible (see page 85).
3. Connect mains power to Monitor Cart and wall power outlet.
4. Power on the Monitor Cart (see page 88).
Wireless communication is established as soon as both carts are powered up.
Connect the potential equalization cable to the Monitor Cart and corresponding wall
outlet before establishing a wireless connection (see page 58).
After establishing the wireless camera communication, do not turn on additional wire-
less devices as it may result in an unwanted interruption of wireless camera commu-
nication.
1. Shut down the system.
2. Disconnect the camera cable.
3. Plug in mains power at Camera Cart (see page 70) and restart the system.
System User Guide Rev. 1.0 Curve Dual Display, Curve Single Display Ver. 1.0
See
Page 90
Page 68
Page 89
