Docking Camera and Monitor Carts
6.3.2

Transport and Parking Position

Warning Label The warning label illustrates the correct parking and transport position for Camera Cart when
docked to the Monitor Cart.
Ensure that the monitor(s) are locked in place in the position indicated on the warning label.
Precautions Only transport the Camera Cart in transport position. It is possible for the extended cantilever arm
to unexpectedly swing outward when movement stops.
Be careful when using the handle on the post to rotate the camera arm as the arm has a wide radius,
which could allow the camera to come in contact with equipment or people.
104
If Camera Cart is not in the proper transport position while moving, an abrupt stop may
cause the camera arm to oscillate.
Ensure that the arms of the Camera and Monitor Carts do not hit people or surround-
ings while it is being moved or adjusted.
System User Guide Rev. 1.0 Curve Dual Display, Curve Single Display Ver. 1.0
Figure 49
