Camera Use
Camera Cart Height The below minimum and maximum height values refer to the range of motion of the Camera Cart -
Curve Dual Display (first value) and Camera Cart - Curve Single Display (second value).
74
2194 mm/
2530 mm
999 mm/
650 mm
System User Guide Rev. 1.0 Curve Dual Display, Curve Single Display Ver. 1.0
Figure 29
