Error Responses

When the NetPA U 2002 SB is unable to execute the command, it returns an error response
to the host. The error response codes and their descriptions are as follows:
E10— Unrecognized command
E12— Invalid port number
E13— Invalid parameter
E14— Not valid for this configuration
E17— Invalid command for signal type

Hardware Reset Modes

ATTENTION:
MODE 1: Hold the Reset button while applying power to restore the unit firmware back to the default factory
firmware. This recovers a unit that has incorrect code or updated firmware running. All user files and
settings are maintained.
MODE 3:
To cause an absolute system reset of the Dante module back to factory default conditions:
With power on, press and hold the reset button for about 3 sec. until the reset LED blinks one time
(once at 3 seconds), then release and within 1 second press Reset momentarily (< 1 second).
Following this reset, the Dante module will proceed to its normal boot sequence. This reset will:
• Set the IP configuration to default settings
• Clear all Dante channel audio routing
Set the Dante device name and channel names to default
•
MODE 5: With power on, press and hold the reset button for about 9 sec. until the Power LED blinks three
times (once at 3 sec., again at 6 sec., again at 9 sec.,), then release and within 1 second press Reset
momentarily (<1 sec.).
Mode 5 performs a complete reset to factory defaults, except for firmware:
• Mix-points are set to unity gain (0 dBFS)
AT input 1 is routed to amp output 1
•
• AT input 2 is routed to amp output 2
• Amp outputs are unmuted and set to -24 dB
Line and AT outputs are unmuted and set to unity gain
•
• Trim blocks will be set to unity gain.
• Gain blocks will be unmuted and set to unity gain
• Any inserted or active DSP is removed
• All line inputs are set to unity gain and are unmuted
All preset and group master memory is cleared
•
• Status monitoring unsolicited repsonses will be turned off
• Standby timer will be enabled
• Unit will not be in standby
• The output mode will be set to 8Ω stereo
The Reset LED flashes 3 times in quick succession during the reset.
The reset modes listed below will Close all open IP and Telnet
connections, and Close All Sockets.
NetPA U 2002 SB User Guide • Remote Control and Communication
E18— System/command timed out
E25— Busy
E25— Device not present
E30— Hardware Failure (followed by colon
and descriptor #)
• AT input 1 is routed to line output 1
• AT input 2 is routed to line output 2
