Cancel Button — (see
7
contained parameters back to their states when the current instance of the Limiter
dialog box was opened and closes the dialog box.
Dynamics Help Button — (see
8
Operation topic of the DSP Configurator Help File for further assistance in operating
dynamics processors.
Input Ducking Block
The duck block contains a ducking processor as well as an adaptive gain processor.
• Ducker (see page 42) — Decreases levels on specified channels when signal is
present above a set threshold on the duck source (trigger).
Adaptive Gain (see page 43) — Increases levels on specified channels when signal
•
is present above a set threshold on the adaptive gain source channel (trigger).
Double-click the Duck block to open the drop-down list
where the Ducker and Adaptive Gain processors can
be selected.
Select Ducker to insert a ducking processor into the duck
block (as seen on the right). Select Adaptive Gain to
insert an adaptive gain processor into the duck block.
Depending on the processor selected, the duck block
displays DUCK for a ducker or AG for adaptive gain.
If a ducking processor has been inserted and needs to be changed to a an adaptive gain
processor, or vice versa, right-click the block and hover over Insert to insert a different
processor (see figure 42).
Figure 42. Changing Ducking Processor
figure 41 on page 40) Reverts any changes made to the
figure 41 on page 40) Opens the Dynamics
NetPA U 2002 SB User Guide • DSP Configurator Software 41
