Figure 29.
1
2
NOTE: If only pushing selected presets, the preset selection dialog box opens
• If only pushing selected presets, mark them from the dialog box shown in figure 30
on the next page.
Figure 30.
Once a push or pull is completed, the current state of the connected unit is
displayed in the DSP Configurator status panel and the device is ready for further
configuration.

Exit Live Mode and Enter Emulate Mode

Click the Emulate button in the DSP Configurator menu bar (see figure 31,
1.
next page). Alternatively, select Tools > Disconnect from Device or press <F6> on
the keyboard.
Synchronize with Device Dialog Box
Pull — Pulls the configuration file and preset configurations from the device
and displays it in the DSP Configurator main workspace.
Push — Pushes the configuration file and preset configurations open in DSP
Configurator to the connected NetPA U 2002 SB. The check boxes indicate
what is pushed when OK is selected. Pushing a selected item overwrites that
item on the device.
after clicking OK, allowing you to select which preset to push to the device.
Preset Selection Dialog Box
NetPA U 2002 SB User Guide • DSP Configurator Software
, on the
1
