Tools
Presets — Contains a submenu to
1
mark and clear elements in the main
workspace as well as an option to
save marked elements to a preset (see
Presets on page 63).
Configure Groups — Opens the
2
Configure Groups dialog box to create,
edit, and delete Gain and Mute groups
(see Groups on page 65).
Configure Amplifier Output Mode —
3
Opens the Configure Amplifier Output
Configuring the
Mode dialog box (see
Output Mode on page 55).
Configure Standby Settings —
4
Opens a submenu to disable or enable
the auto-standby timer or force standby
mode.
Connect/Disconnect from Device — When in Emulate mode, this reads as
5
Connect to Device and opens the Connect to Device dialog box (see
Connect/Disconnect from Device
Disconnect from Device and returns software to Emulate mode.
Device Manager — Opens the Device Manager dialog box (see
6
on page 67).
Issue RESET Command — Clears the amplifier of all processors and other
7
configuration settings. This command does not reset general settings such as IP
address (see Hardware Reset Modes
Firmware Loader — Opens the Firmware Loader application, if it is installed (see
8
Firmware Loader on page 70). Visit
Organize Building Blocks — Opens the Organize Building Blocks dialog box
9
(see Organize Building Blocks
Device Settings — Opens the Device Settings dialog box to edit date and time,
¢
IP address, DHCP status, and other settings (see
Options — Opens the Options dialog box to configure DSP Configurator
£
appearance, default settings, DSP value defaults, and so on (see
page 74).
Network Audio Control — Opens the Dante Controller application by Audinate
¤
for routing audio over a Dante network (see
Window
Cascade — Organizes windows by
1
cascading them in the same order they were
opened.
Close All Windows — Closes all open
2
windows, leaving only the main workspace
visible. When all windows are closed,
parameter changes are saved before the
window is closed.
1
2
3
4
5
6
7
8
9
¢
£
¤
on page 69). When in Live mode, this reads
on page 89).
www.extron.com
on page 71
).
Device Settings
Dante Controller
1
2
NetPA U 2002 SB User Guide • DSP Configurator Software
Device Manager
to download the software.
on page 72)
.
Options on
on page 75).
