Emulate Mode
While in Emulate mode, DSP Configurator is functioning in an "offline" state. Changes made
to the configuration file are not applied to a device.
In Emulate mode, the user can create and configure the software as though a device was
connected, except for any actions that require direct connection to the device or information
that is stored only on the device. Once configuration is complete, the user can switch to
Live mode and apply the configuration to the device or save the configuration file to be
loaded onto one or multiple devices at a later time.
Creating configuration files in Emulate mode saves time by not requiring a device to be
connected or present in order for the bulk of DSP configuration to be completed.
NOTE: Not all menu options or actions are available in Emulate mode.
Live Mode
Enter Live mode to connect to the NetPA U 2002 SB amplifier and push or pull
configurations between the device and host PC. In Live mode, changes made in DSP
Configurator are directly applied to the NetPA Ultra Series amplifier. Additionally, presets can
be created and stored on the device.
When entering Live mode, the user is prompted with the Connect to device dialog box.

Connect to a NetPA U 2002 SB Amplifier in Live Mode

Click the Live button in the menu bar of DSP Configurator (see figure 25,
1.
Alternatively, select Tools > Connect to Device or press <F6> on the keyboard. The
Connect to device... dialog box opens (see figure 25).
Figure 25.
2. Connect to the amplifier.
• To connect via USB:
Click the USB tab in the dialog box. Select the device from the USB Devices
drop-down list.
Figure 26.
Live Button
Connect to device... USB Dialog Box
