To arrange devices into a folder:
From the Device Manager dialog box, click the New Folder button (see figure figure 75,
1
Enter a name for the folder. The text for the folder name is automatically highlighted and
ready to be edited (
NOTE: Folders can be renamed later by clicking twice on the folder name and
5.
6.

Connect/Disconnect from Device

When DSP Configurator is in Emulate mode, this selection in the Tools menu reads
Connect to Device and opens the Connect to device... dialog box when selected.
When DSP Configurator is in Live mode and connected to a device, this selection reads
Disconnect from Device and disconnects DSP Configurator from the current device
when selected, and returns to Emulate mode.
For detailed instructions on connecting to an amplifier, see
SB Amplifier in Live Mode
from a NetPA Ultra Series amplifier, see
page 33.
).
).
2
editing the text.
Press <Enter>.
Click and drag devices over the folder name and release to insert the devices into a
folder ( ).
3
1
2
Figure 76. Arranging Devices Into a Folder
on page 31. For detailed instructions on disconnecting
3
Connect to a NetPA U 2002
Exit Live Mode and Enter Emulate Mode
NetPA U 2002 SB User Guide • Configurator Tools
on
69
