Receiver and Transmitter Names

In addition to renaming a device, individual transmitter and receiver channels can be
renamed in Dante Controller. Rename transmitter and receiver channels to reflect the
location of the device or the purpose of the transmitter or receiver. Ensure transmitter and
receiver channels are renamed before making audio connections between devices. Refer to
Renaming a Receiver or Transmitter

Dante Controller Naming Conventions

Device names follow Domain Name System (DNS) hostname rules. Legal characters are
•
A-Z, a-z, 0-9, and hyphen (-). Names must begin with a letter and cannot end with a
hyphen (-).
• Dante Tx and Rx channel names (also known as labels) can be up to 31 characters
in length. Label names are not case-sensitive. For example, "ANALOG OUT-1" and
"analog out-1" are recognized as the same name. Unicode and non-roman
characters are not supported.
Tx and Rx channel labels can use any character except equals (=), period (.), or @.
•
Tx and Rx channel labels must be unique on a device but do not need to be unique on
•
the network.

Renaming the NetPA U 2002 SB Amplifier in Dante Controller

NOTE: Dante device naming can also be done via DSP Configurator (see
on page 73).
1.
Ensure that the control computer and a single NetPA Ultra Series amplifier is connected
to the same network.
From the control computer Start menu select:
2.
All Programs>Audinate>Dante Controller>Dante Controller
The Dante Controller - Network View screen opens. All Dante devices on the
3.
network are discovered and listed.
4. From the Device menu, select Device View or press <Ctrl+D> on the keyboard (see
figure 104).
Figure 81.
The Dante Controller - Device View dialog opens. Select the device being
5.
configured from the (Select a Dante Device...) drop-down list (see figure 82,
Figure 82.
on page 79 for renaming procedure.
Opening Device View
1
Device View and Select a Dante Device Drop-Down
NetPA U 2002 SB User Guide • Dante Controller
Dante Device
).
1
77
