Exit Live Mode and Enter Emulate Mode

1.
2.
DSP Configurator Inputs
All available inputs are listed vertically along the left side of the DSP Configurator main
workspace. The input groups can be expanded or collapsed by clicking the (expand) or
(collapse) buttons next to the input group names.
There are two types of inputs available:
•

Mic/Line Inputs

The four mic/line input channels in the NetPA Ultra Series amplifier are shown in
DSP Configurator under the Inputs panel.
Figure 33.
Inputs 1 - 4 can receive mic level or line level signals.
Naming an Input Channel
1.
2.
3.
Click the Emulate button in the DSP Configurator
menu bar (see the image on the right,
Alternatively, select Tools > Disconnect from
Device or press <F6> on the keyboard.
Click OK to confirm.
Figure 32. Confirm Disconnect
Mic/Line Inputs
Inputs Panel
Click the input name field.
Highlight or delete the text and enter a new name.
Press <Enter> or navigate away from the field to confirm and
apply the new input name.
Press <Down Arrow> key to navigate to and highlight the next
name field.
NOTE: Follow the same procedure to edit an input name.
).
1
AT Inputs
•
NetPA Ultra Series • DSP Configurator Software 34
