Appendix F Pin Assignments
Power
Connector
Fault-bus
(Main Board)
SCSI Channel 1
Fault-bus Connector
486DX2-66
Pin 1
1
RS-232C Port
Pin
Descriptions
1
DCD1
2
RXD1
3
TXD1
4
DTR1
5
GND
Appendix F Pin Assignments
COM 1
RS-232C
SCSI Channel 0
SCSI Channel 2
Infortrend
500127-S10
34
33
JP18
SIMM-1
SIMM-2
Pin
6
DSR1
7
RST1
8
CTS1
9
RT1
10
N/C
COM 2
Redundant Controller Port
Fault-bus
(Daughter Board)
JP16
Descriptions
F-1
