Chapter 10 Redundant Host,
Multiple Host
Redundant Host
RAID
Controller
CH 0
CH 1
Host A
CH 2
CH 3
CH 4
CH 5
Add
daughter board
for more channels
Host B
The AA-3102RS RAID controller can connect and serve redundant
host computers. The figure above is an example of connecting to
redundant host computers.
The Logical drives can be accessed by two host computers at the
same time. The host redundant management hardware/software
should avoid data conflict when more than one host computers are
accessing the same logical drive.
Chapter 10 Redundant Host, Multiple Host
Terminator
.....
Up to 15
drives
Terminator
.....
Up to 15
drives
Terminator
.....
Up to 15
drives
Terminator
.....
Up to 15
drives
Terminator
.....
Up to 15
drives
