Chapter 8 RS-232C Terminal
Interface
Understanding the Information on the Screen
The Initial Screen
Cursor Bar
Item
Cursor Bar
Move the cursor bar to a desired item, then press
ENTER to select.
Identifies the type of controller.
Controller
Name
Indicates the current data transfer rate.
Transfer Rate
Indicator
Gauge Range
Use + or - keys to change the gauge range in order
to view the transfer rate indicator.
Cache Status
Indicates the current cache status.
Chapter 8 RS-232C Terminal Interface
Controller Name
Transfer Rate Indicator
Description
Cache Status
Gauge Range
