2. Provide the firmware filename to the Acer RAID Manager . It will
start to download the firmware to the controller.
3. Shutdown the system which is accessing the RAID, then reset the
controller in order to use the new downloaded firmware.
Upgrading firmware using RS-232 Terminal Emulation
The firmware can be downloaded to the RAID controller by using an
ANSI/VT-100 compatible terminal emulation program. Whichever
terminal emulation program is used must support the ZMODEM file
transfer protocol. The following example uses the HyperTerminal in
Windows NT. Other terminal emulation programs (e.g., Telix and
PROCOMM Plus) can perform the firmware upgrade as well.
Establishing the connection for the RS-232 Terminal Emulation
Please refer to chapter 4 section "Serial Port Connection and Set-up"
for details on establishing the connection.
Upgrading Both Boot Record and Firmware Binaries
C-4
User's Guide
