Grid-Tie Sell

The following descriptions apply to grid-interactive inverter models only. In other models, these menus
are inoperative.
This menu controls the limits of the inverter's "grid-tie" or grid-interactive function. See the inverter
Operator's Manual for an explanation of the grid-interactive function and how it relates to the regular
charging process.
To access the Grid-Tie Sell menu:
1. Access the Inverter menu as shown in Figure 71 on page 75.
2. Use the control wheel to highlight the Grid-tie Sell menu.
Press the button in the center of the control wheel to accept the selection.
3. Use the control wheel to change the Grid-Tie Enable to Y (Yes) or N (No).
Press the button in the center of the control wheel to accept the selection.
This should automatically move the highlighting to the next set point.
4. Use the control wheel to change the Sell Voltage set point.
Press the button in the center of the control wheel to accept the selection.
This should automatically move the highlighting to the next set point.
5. Use the control wheel to change the Grid-Tie Window set point to User or IEEE.
Press the button in the center of the control wheel to accept the selection.
This should automatically move the highlighting to the next set point.
6. After setting the parameters for each set point, press the TOP navigation key to return to the
Main Menu screen.
90
IMPORTANT:
On grid-interactive models only:
The grid-interactive function can sell power using the input connection. This function
only operates if Grid is selected in the
function if Gen is selected.
Figure 87
AC Transfer Control menu. It does not
Grid-Tie Sell
