Figure 1 Mate3 Features - Alpha Group OutBack Power MATE3 Owner's Manual

INVERTER Hot Key
Inverter Status LED (Yellow)
CHARGER Hot Key
Charger Status LED (Green)
GEN(erator) Hot Key
GEN Status LED (Green)
Soft Keys (x4)
TOP Navigation
Key
LOCK Key
Side View
SD
Memory
Card Slot
14
Battery Status LEDs (x3)
Control Wheel
Ethernet Port
(Computer)
Figure 1
LCD Screen
ENTER Button
Back View
Port to HUB or
OutBack Device
MATE3 Features
Introduction
EVENTS Hot Key
Event LED (Red)
SD Memory Card
AC INPUT Hot Key
AC Status LED (Yellow)
FAVORITE Hot Key
Favorite Status LED (Green)
UP Navigation Key
PORT Navigation Key
900-0117-01-00 Rev A
