Software Update - Alpha Group OutBack Power MATE3 Owner's Manual

Software Update

The Software Update screen enables the MATE3 to download the latest software revision from an SD
Memory Card (included). Contact OutBack Technical Support (see inside cover of this manual) for
instructions on receiving the latest software revision.
To access the Software Update Screen:
1. Power up the MATE3 by connecting the Cat5 cable to the rest of the system.
2. Insert the SD Memory Card according to Figure 131.
3. Access the Main Menu as shown on page 60.
Front
SD Memory Card
4 GB Maximum
900-0117-01-00 Rev A
Back
allow 2" clearance for insertion of SD Card
Front View
Figure 131 SD Memory Card Slot
Software Update
Side View
135
