Event Messages

To investigate Event Messages:
1. Look at the System indicator. The icon will change to indicate the device that needs attention. See
Legend in Figure 134.
2. Check the LED
~ Flashing means a warning type event has occurred.
~ Solid means an error has occurred.
These system indicators are often specific to certain products or
system configurations, as noted in the table. See pages 26 and
27 for details.
138
Look
System Indicator Legend
System Operational
OK
!
Check Battery (with FNDC only)
X
Battery Critical (with FNDC only)
!
Check Generator (Off Grid system type only)
!
Check Inverter
Check Utility Grid
!
(with grid-tie inverter only)
Figure 133
Check
Event Notification
Troubleshooting
900-0117-01-00 Rev A
