SMC Networks EX600-SEC Series Operation Manual page 97

•Modular Device Profile
Index
F000:0 Modular Device Profile / Length of this object
Module Index Distance /
F000:01 Module Index Distance between two modules
(maximum number of objects per module and area.)
F000:02 Maximum Number of Modules
•Module Ident List of the Configured Modules
Index
F030:0 Module List / Length of this object
F030:01 Subindex 001 / Module ident for Connected Unit 1
• • • • • •
F030:0A Subindex 010 / Module ident for Connected Unit 10
F030:0B Subindex 011 / Module ident for Diagnostic Data
•Module Ident List of Detected Modules
Index
F050:0 Module List / Length of this object
F050:01 Subindex 001 / Module ident for Connected Unit 1
• • • • • •
F050:0A Subindex 010 / Module ident for Connected Unit 10
F050:0B Subindex 011 / Module ident for Diagnostic Data
Table. Modular Device Profile
Name / Meaning
Table. Module Ident List of the Configured Modules
Name / Meaning
Table. Module Ident List of Detected Modules
Name / Meaning
-96-
Type
USINT 2
UINT 0x0010 (16dec)
UINT 0x000B (11dec)
Type
USINT 11
UINT Unit ID
• • • • • •
UINT 0 or unit ID
UINT 0 or 256 or 257
Type
USINT 11
UINT Unit ID
• • • • • •
UINT 0 or unit ID
UINT 0 or 256 or 257
Value
Value
Value
No.EX##-OMO0027
