Part No.
No. Problem
EX600-
Red LED is ON.
(Diagnosis is
activated)
"0 and 1" red
LEDs are ON.
5 AXA
Red LED is
flashing.
(Diagnosis is
activated)
Red/green all
LEDs are
flashing.
Red LED is ON.
(Diagnosis is
activated)
Red LED is
6 AYA flashing.
(Diagnosis is
activated)
Red/green all
LEDs are
flashing.
∗: Refer to "Diagnostic" (page 63) for details.
Presumed cause
Diagnosis error
Analogue input device
power supply is
short-circuited.
Input value has exceeded
the upper limit when set to
current input type range.
Diagnosis error
(1)Input value has
exceeded the upper or
lower limit of the range.
(2)Input value (value set by
user) has exceeded the
upper or lower limit.
Unit has failed
Diagnosis error
Analogue output device
power supply is
short-circuited.
Diagnosis error
Output value (value set by
user) has exceeded the
upper or lower limit.
Unit has failed
-34-
Troubleshooting
Check the parts with error by using the LED display or
∗
master or H.T. Re-wire the short-circuited part, and
check if the cable and analogue input device are normal.
Check the following when the range of the Analogue
input unit is set to current input.
(1)Set the input value of the analogue input device so
that it does not exceed the upper limit.
(2)Voltage is input from the analogue input
device.Ensure the range of the Analogue input unit
matches the range of the analogue input device.
(1)If the input value from the analogue input device
exceeds the upper or lower limit of the range, select
the appropriate range so that the input value is within
the range. Or invalidate diagnosis.
(2)If the input value from the analogue input device
exceeds the upper or lower limit of the user set value,
adjust it so that the input value is within the range of
the user set value. Or invalidate diagnosis.
Stop the operation and contact SMC.
Check the parts with error by using the LED display or
∗
master or H.T. Re-wire the short-circuited part, and
check if the cable and analogue output device are
normal.
If the output value from the analogue output device
exceeds the upper or lower limit of the user set value,
adjust it so that the output value is within the range of
the user set value. Or invalidate diagnosis.
Stop the operation and contact SMC.
